The Perimeter Surveillance Terminal is an intelligent perimeter surveillance system. It uses state of the art multi-sensor technology and multi-stage decision hierarchy to maximize situational awareness, all inside a single unit. It contains built-in radar and camera, plus smart target recognition and classification. This enables reliable detection and proactively alert of intrusions. By adopting a software framework based on continual learning and automatic model deployment, Perimeter Surveillance Terminal is able to rapidly adapt to the various environmental changes of the installation site, ensuring system accuracy and optimal user experience. It can be used for perimeter security of parking lots, data centers, commerical buildings, and important infrastructures in a variety of settings.
| Model | AXPW60 |
| Detection Range | Up to 60m (197ft) |
| Target Classification | Humans, Animals |
| Target Velocity | 0.2 ~ 20m/s (0.7 ~ 65.6ft/s) |
| Detection Accuracy | High detection ratio with extremely low false detection (up to 99.99% accurate detection against 1 false alert monthly in lab condition) |
| Simultaneous Tracking | Up to 32 targets |
| Deep Learning Algorithm | Supported |
| System Self-diagnose | Supported |
| Alarm Zones | Up to 4 customized alarm zones with different security levels. |
| Tamper Alarm | Supported |
| Line-cut Alarm | Supported |
| Local Storage | Supported |
| Cameras | HD 1080P 2MP IR Camera (h.265) |
| Radar | MIMO Radar @60GHz with high resolution and low dalse alarm rate with 120° field of view |
| Video/image Capture | Full HD 1080p daylight and lowlight |
| Strobe Siren Alarm | 120 dB |
| Communication Interface | RJ45 10M / 100M self-adaptive Ethernet Interface |
| Installation | Power and Ethernet required. 2.5m (8ft) above the ground |
| Operating System | Windows/Linux |
| IP Rating | IP66 |
| Third-party Integration | SDK /API |
| Protocol | TCP /IP |
| Connectivity | Ethernet |
| Power Supply | 12V DC |
| Working Temprature | -20 ~ 70°C with -40 ~ 70°C optional (-4 ~ 158℉ with -40 ~ 158℉ optional) |
| Dimension | 100*140*60mm (3.9*5.5*2.4in) |
| Weight | ＜2kg (＜4.4lb) |
