*Note that appearances, specifications and functions may be different without notice.
SPECIFICATIONS | |
| Model | AXDVW2 |
| Intended Use | |
| Suitable for |
|
| Core Functions | |
| Product functions | Respiration, heart rate, and body temperature (optional) monitoring |
| Anomaly alerts | Vital signs anomaly alerts (Abnormal respiratory rate / heart rate / body temperature) |
| Temperature control | √ |
| APP functions | Remote viewing (optional), real-time respiratory rate, real-time heart rate, etc. |
| Hardware & Components | |
| Key components | Starter control panel, external socket, heating unit |
| Infrared camera | Optional |
| Power | |
| Power supply | AC 100-240V, 50/60Hz Heating unit: Supports 110V / 220V voltage adaptation |
| Power consumption | 41 W (normal), 206 W (peak: when heating at 50°C / 122℉) |
| Network | |
| Communication interface | WiFi |
| Environment | |
| Operating Temperature | -10 ~ +50 (°C) / 14 ~ 122 (℉) |
| Dimension and weight | |
| Dimension | 938×754×605 (mm) / 40×30×24 (in) |
| Weight | 57 (kg) / 126 (lb) |
